Form Factor
|
1U rack
|
|
Processor
|
Intel Xeon E5-2407 (2.20GHz, 10M Cache, 6.4GT/s QPI, No Turbo, 4C/4T, TDP 80W)
|
|
Processor Sockets
|
2
|
|
Internal interconnect
|
Intel QuickPath Interconnect (QPI) link: 6.4GT/s, 7.2GT/s, 8.0 GT/s
|
|
Cache
|
2.5MB per core, Core options: 2, 4, 6, 8
|
|
Chipset
|
Intel C600 series
|
|
Memory
|
8GB (1 x 8GB RDIMM, 1333 MHz, Low Volt, Dual Rank, x4)
Up to 192GB (12 DIMM slots): 2GB/4GB/8GB/16GB DDR3 up to 1600MHz
|
|
Hard Drives
|
NO HDD's
Hot-plug hard drive options:
2.5” SATA, nearline SAS, SAS (15K, 10K), SAS SSD, SATA SSD
3.5” SATA, nearline SAS, SAS (15K)
Self-encrypting drives available
Cabled hard drive options:
3.5” SATA, nearline SAS, SAS (15K)
|
|
Maximum Internal Storage
|
Up to 12 TB
|
|
Drive Bays
|
Up to eight 2.5” hot-plug SSD, SAS, or SATA or up to four 3.5” hot-plug SAS, SATA, or SSD
|
|
RAID Controller
|
PERC H310 Integrated RAID Controller
|
|
I/O slots
|
2 PCIe slots
With two processors:
• One x16 PCIe slot with x16 bandwidth, half-length, falf-height
• One x16 PCIe slot with x16 bandwidth, half-length, full-height
With one processor:
• One x8 PCIe slot with x4 bandwidth, half-length, half-height
• One x16 PCIe slot with x16 bandwidth, half-length, full-height
|
|
Communications
|
Broadcom 5720 GbE Dual Port
|
|
Optical Drive
|
16x DVD+/-RW Drive
|
|
Remote Management
|
iDRAC Enterprise
|
|
Power Supply
|
Dual Hot Plug Power Supplies 550W
|
|
Systems Management
|
IPMI 2.0 compliant
Dell OpenManage™ Essentials and Dell Management Console
Dell OpenManage Power Center
Dell OpenManage Connections:
• OpenManage Integration Suite for Microsoft® System Center
• Dell plug-in for VMware® vCenter™
• HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management
|
|
Availability
|
High-efficiency, Hot-Plug, Redundant power supplies, Hot-Plug hard drives, TPM, Dual internal SD Module 2x1GB, Fan fault tolerance, Luggage tag, ECC memory, Interactive LCD screen, ENERGY STAR® compliant
|
|
Rack Support
|
ReadyRails sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks)
|
|
Εγγύηση 5 χρόνια - Next Business Day On-Site
|
