Form Factor
|
Tower (5U rackable)
|
|
Processor
|
Intel Xeon E5-2630 (2.30GHz, 15M Cache, 7.2GT/s QPI, Turbo, 6C/12T, 95W)
|
|
Processor Sockets
|
2
|
|
Internal interconnect
|
2 x Intel QuickPath Interconnect (QPI) links, 6.4 GT/s, 7.2 GT/s, 8.0 GT/s
|
|
Cache
|
2.5MB per core
Core options: 2, 4, 6, 8
|
|
Chipset
|
Intel C600
|
|
Memory
|
16GB (2 x 8GB RDIMM, 1333 MHz, Standard Volt, Dual Rank, x4)
Up to 768GB (24 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s
|
|
Hard Drives
|
- 2 x 500GB, SATA, 3.5", 7.2K rpm Hard Drive (Hot-plug)
- 4 x 1TB, SATA, 3.5", 7.2K rpm Hard Drive (Hot-plug)
Hot-plug hard drive options:
2.5" PCIe SSD, SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K)
3.5" nearline SAS (7.2K), SATA (7.2K), SAS (15K)
Self-encrypting drives available
|
|
Maximum Internal Storage
|
Up to 36TB
|
|
Drive Bays
|
Up to 12 x 3.5” hot-plug drive bays
|
|
RAID Controller
|
PERC H710 Integrated RAID Controller, 512MB NV Cache
|
|
I/O slots
|
7 PCIe slots:
• Four x16 slots with x16 bandwidth, full-length, full-height
• Two x8 slots with x8 bandwidth, full-length, full-height
• One x8 slot with x4 bandwidth, full-length, full-height
|
|
Communications
|
Intel Dual Port 1GbE LOM
|
|
Optical Drive
|
16x DVD+/-RW Drive
|
|
Remote Management
|
iDRAC Express
|
|
Power Supply
|
Redundant Power Supply (1+1), 1100W
|
|
Systems Management
|
IPMI 2.0 compliant
Dell OpenManage™ Essentials and Dell Management Console
Dell OpenManage Power Center
Dell OpenManage Connections:
• Dell OpenManage Integration Suite for Microsoft® System Center
• Dell plug-in for VMware® vCenter™
• HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management
|
|
Availability
|
High-efficiency, hot-plug, redundant power supplies, hot-plug drive bays, TPM, dual internal SD support, hot-plug redundant fan, optional bezel, luggage-tag, ECC memory, interactive LCD screen, extended thermal support, ENERGY STAR® compliant, extended power range, switch independent partitioning
|
|
Rack Support
|
ReadyRails II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm
|
|
Εγγύηση 5 χρόνια - Next Business Day On-Site
|
